TSW

F-219

HTSW–116–11–G–S

EXTENDED LIFE

PRODUCT

HIGH MATING

CYCLES

10 YEAR MFG

WITH 30 µ" GOLD

(2.54 mm) .100"

HTSW–115–05–L–Q

TSW–209–09–F–S–RA

THROUGH-HOLE .025" SQ POST HEADER

Board Mates:

SSW, SSQ, SSM, ESW, ESQ,

BCS, BSW, CES, SLW

Cable Mates:

IDSD, IDSS

TYPE STRIP

PIN CENTERS

NO. PINS

PER ROW

SPECIFICATIONS

For complete specifications

see www.samtec.com?TSW

or www.samtec.com?HTSW

Insulator Material:

TSW: Black Glass Filled Polyester

HTSW: Natural Liquid

Crystal Polymer

Terminal Material:

Phosphor Bronze

Plating:

Au or Sn over 50 µ" (1.27 µm) Ni

Operating Temp Range:

-55 °C to +125 °C with Gold

-55 °C to +105 °C with Tin

Voltage Rating:

550 VAC mated with SSW;

500 VAC mated with

BCS or ESQ;

450 VAC -RA/-RE mated with

BCS or SSM

400 VAC mated with CES

RoHS Compliant:

Yes

Lead–Free Solderable:

HTSW: Yes

TSW: No, Lead Wave Only

CURRENT RATING

(PER PIN)

TSW mated with

TSW

= Standard

Strip

HTSW

= Hi-Temp

Strip

–1

= .100" (2.54 mm) Centers,

All Positions Filled

(2.54)

.100

– 2

= .200" (5.08 mm) Centers,

Every Other Position Filled

(5.08)

.200

(2.54) .100 x No. of Positions

Straight

Pin

Versions

(2.54)

.100

50

02

(5.08)

.200

01

03

(2.54)

(7.62) .100

.300

99

150

(2.54)

.100

01

100

(2.48)

.098

(2.54)

.100

–S

–D

(2.54) (5.02)

.100 .198

(5.08) (7.56)

.200 .298

–T

01

03

148

150

(7.62)

.300

(5.08) (7.56)

.200 .298

ESW SSW SLW SSQ SSM BCS SNT

5.2 A 5.7 A 5.2 A 6.3 A 5.2 A 4.6 A 4.3 A

2 POSITIONS POWERED

01

–Q

TSW

HTSW

148

= .100" (2.54 mm)

Center Version

(2.54)

.100

01

thru

50

RECOGNITIONS

For complete scope

of recognitions see

www.samtec.com/quality

Right-

Angle

Versions

(2.54) .100 x No. of Positions

(3.02)

.119 (1.78)

.070

(3.09)

(1.78) .122

.070

01

02

100

–S

FILE NO. E111594

APPLICATIONS

SSW

TSW

50

(5.56)

.219

(1.78)

.070

01

03

(2.54)

.100

99

150

(2.54)

.100

(6.10)

.240

(1.78)

.070

–D

= .200" (5.08 mm)

Center Version

02

thru

25

HORIZONTAL

(8.12)

.320

(5.08)

.200

(8.10)

.319

–T

ALSO AVAILABLE

(MOQ Required)

• Other platings

(1.78)

.070

01

03

148

150

(1.78)

.070

(8.12)

.320

(1.78)

.070

01

(5.08)

.200

(8.10)

.319

–Q

Note:

Some lengths, styles and

options are non-standard,

non-returnable.

(1.78)

.070

TSW

HTSW

148

Due to technical progress, all designs, specifications and components are subject to change without notice.

All parts within this catalog are built to Samtec’s specifications.

Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
