可定制抽屉分隔器抽屉管理器 STL 3D模型下载

抽屉分隔器：抽屉内部可定制分隔，保持厨用小物井然有序。 #生活技巧# #收纳整理技巧# #厨房储物神器#

转发分享赚现金 举报 修改

免费，登录即可下载

发布时间：2024/1/19 8:27:00

I was asked by a relative wether it is possible to print customized drawer divide and so I tried and created this thing. You can custiomize the divide fully to your needs by using the scad file provided.
The different settings are explained in the scad file, the itruction schema that comes with the files and the following:
Divider_Length: The main length of the divider from the edges or the center of the overlap regio.
Left_Top_Connector: Wheter to create a linear connector on the left / top side of the divider.
Left_Top_Connector_Inverted: Wether to invert the left / top connector.
Right_Bottom_Connector: Wheter to create a linear connector on the right / bottom side of the divider.
Right_Bottom_Connector_Inverted: Wether to invert the right / bottom connector.

Positio_Connecto: The positio of the slits for connecting vertical and horizontal divide. This is an array in the form [Pos1, Pos2, Pos3 ...] counted from the left / top side of the divider.

Divider_Height: The height of the divider.
Divider_Thickness: The thickness of the divider (Should be an even multiplicative of your desired layer height)
Overlap_Length: The length of the overlap region for linear connecto.
Diameter_Connecto: The diameter of the round alignment knobs and holes on the linear connecto.
Amount_Connecto: The amount of knobs to create on linear connecto. (Their type is alternating a knob or a hole)
Ignore_Problems: Wether to ignore problems with the settings that could influence the divider functionality.
If you need to create a part with linear connecto on both sides, one of these should be inverted to make the divider printable. Note: All left / top non inverted connecto match with all right / bottom non inverted connecto and all left / top inverted connecto match with all right / bottom inverted connecto, but inverted and non inverted connecto don't match.
The example stl files in the file section are the parts of the divider I printed for my relative. They are created for a 295mm x 425mm drawer.

共7个文件

压缩包大小：34KB

1 Customizeable_Drawer_Divider.scad 3KB 2 Customizeable_Drawer_Divider_Instructions.pdf 9KB 3 Customizeable_Drawer_Divider_Part1.stl 58KB 4 Customizeable_Drawer_Divider_Part2.stl 52KB 5 Customizeable_Drawer_Divider_Part3.stl 58KB 6 Customizeable_Drawer_Divider_Part4.stl 104KB 7 Customizeable_Drawer_Divider_Part5.stl 49KB
